| Model: BLY-2G2E-F / BLY-2F4E-F / BLY-4G2E-F / BLY-8G8E-F |
| Category |
Parameter |
BLY-2G2E-F |
BLY-2F4E-F |
BLY-4G2E-F |
BLY-8G8E-F |
| Features |
Electrical port |
2×100/1000Base-TX RJ45 |
4×100/1000 Base-TX RJ45 |
2×100/1000Base-TX RJ45 |
2×100/1000Base-TX RJ45 |
| Optical port |
2×1000 Base-FX SC |
2×1000 Base-FX SFP |
4×1000 Base-FX SFP |
8×1000 Base-FX SFP |
| Transmission rate |
1.25 Gbps |
1.25 Gbps |
1.25 Gbps |
1.25 Gbps |
| Wavelength |
850/1310/1490/1550 nm |
850/1310/1490/1550 nm |
850/1310/1490/1550 nm |
850/1310/1490/1550 nm |
| Transmission distance |
550m~100KM |
550m~100KM |
550m~100KM |
550m~100KM |
| Back bandwidth |
4 Gbps |
12 Gbps |
12 Gbps |
32 Gbps |
| Housing |
Dimensions |
94x70x26 mm |
160x82x26 mm |
160x82x26 mm |
160x82x26 mm |
| Weight |
0.2 kg |
0.3 kg |
0.3 kg |
0.5 kg |
| Material |
High quality iron shell |
High quality iron shell |
High quality iron shell |
High quality iron shell |
| Installation |
Desktop installation |
Desktop installation |
Desktop installation |
Desktop installation |
| Power |
Power Input |
5~12V DC |
5~12V DC |
5~12V DC |
5~12V DC |
| Interface |
DC:55.25mm External power supply |
DC:55.25mm External power supply |
DC:55.25mm External power supply |
DC:55.25mm External power supply |
| Power Consumption |
Full load <3W |
Full load <3W |
Full load <3W |
Full load <3W |
| Environment |
Temperature |
-20℃~60℃ |
-20℃~60℃ |
-20℃~60℃ |
-20℃~60℃ |
| Humidity |
5%~95% RH No condensation |
5%~95% RH No condensation |
5%~95% RH No condensation |
5%~95% RH No condensation |
